14 Order Overview
Multifunctional Danger Control and Indicating Panels SIGMASYS C and M (M-Modules) 107 / 128
Best.Nr. A24205-A337-B970 – Edition 12 (03/07)
Name Order number Remark
All-or-nothing relay A5Q00001243 Two 8 A / 24 V changeover contacts
LA Interface P S24211-A418-A2 Extinguishing interface for PMG-S
LA Interface S S24211-A418-A4 Extinguishing interface for Loop
SIGMALOOP Extinguishing interface
S24230-A352-A1
For extinguishing interface 2 Outputs, 7 In-
puts or 7x FSA control facility
PC board block 32 pins V24068-Z7102-A1
For extinguishing interface S24230-A352-A1
and S24230-A353-A1
PC board block C24104-Z18-C1
For extinguishing interface S24211-A418-
A2, S24211-A418-A4
SIGMALOOP Splitter S24218-B45-A1
Creates four spur lines from a single SIGMA
spur line
SIGMANET P coupler SIGMASYS C
S24230-B71-A1
Mechanical kit including SOC P and
APL20P
SIGMANET P coupler SIGMASYS op-
erating panel
S24230-B72-A1
Mechanical kit including SOC P and
APL20P
SIGMANET P coupler empty housing
S24230-B73-A1
Mechanical kit including SOC P and
APL20P
Sinteso
TM
peripheral elements connectable to FDnet (FDC)
Automatic detectors
FDT221 heat detector A5Q00001567 C-Line
FDT241 heat detector A5Q00004812 S-Line
FDO221 smoke detector A5Q00001565 C-Line
FDO241 smoke detector A5Q00004811 S-Line
FDOOT221 neural fire detector A5Q00001566 C-Line
FDOOT241-9 neural fire detector A5Q00004813 S-Line FDnet and GMG
FDOOT241-8 neural fire detector A5Q00004663 S-Line FDnet and PMG
FDB221 addressable detector base A5Q00001664 FDT/FDO 221/241, FDOOT221/241
FDB201 collective detector base A5Q00003814 for FDOOT241-9 on BMZ with GMG
FDB291 additional base A5Q00001603 for cable >6mm diameter
FDB292 wet base A5Q00003940 for installation in wet environments
FDB281 base adaptor for MS8/P2 A5Q00004929 Adapter for Sinteso on MS8 base
FDBZ291 detector code A5Q00002621
FDBZ293 detector locking device A5Q00005035
DBZ1194 protective cage GBI:1467711
FDBH 291 detector heating unit A5Q00004439
FDSB291 signal base A5Q00001647 for FDO 221/241, FDOOT 221/241
Special detectors
FDF221-9 flame detector A5Q00003902 C-Line one-eyed (no interference)
FDF241-9 flame detector A5Q00003006 S-Line two-eyed (sun resistance)
FDFB291 flame detector base A5Q00003310 Base for FDF221-9, FDF241-9
FDL241-9 linear smoke detector A5Q00002298 S-Line
FDLB291 linear detector base A5Q00003941 for FDL241-9
Manual detectors
Hfm red FDM223 (complete) A5Q00008098 Complete with shield and cable gripper
FDMH223 L24213-L8000-A224 With reinforced housing
FDME223 switching unit A5Q00003087 Pushbutton detector unit
FDMH293-R housing red A5Q00004023 Housing for pushbutton detector unit
Window shield GBI:1530415 Fire brigade/fire alarm
Cable gripper GBI:20671 for AP cable entry
