Siemens SIGMASYS M User Manual

14 Order Overview
108 / 128 BMT Project Planning Guidelines
Best.Nr. A24205-A337-B970 – Edition 12 (03/07)
Name Order number Remark
Miscellaneous elements
FDS221 alarm sounder A5Q00004117 connectable to FDB221
FDCL221 line disconnector A5Q00004011
for more than 1 T-spur between 2 Sinteso
elements 1x per spur
FDCI222 (4x) input module A5Q00001984 4 inputs
FDCIO222 input/output module A5Q00002369 4 inputs and 4 relay outputs
FDCIO223 FDnet transponder S24218-B102-A1 Available from mid-2006
FDCIO224 VdS exting. interface A5Q00018689 FDnet extinguishing interface
FDCH291 housing A5Q00002395 for FDCI(O)222 and FDCIO223
FDCM291 mounting base A5Q00003855
for mounting a top hat rail
2x per FDCI(O)222 ( 223 ) required
DJ1191 external alarm indicator GBI:1478328 H x W x D (dim. in mm): 37 x 62 x 17
DJ1192 external alarm indicator GBI:1478331 H x W x D (dim. in mm): 85 x 85 x 25
Fdnet extinguishing interface
FDCIO224 input/output module A5Q00018689
All-or-nothing relay A5Q00001243
SMxx extinguishing interface S24230-A353-A1
PC board block 32-pin V24068-Z7102-A1
Configuring commissioning and tools
SIGMASYS
SIGMAPLAN S24236-P43-Ax
SIGMADIAG S24236-P41-A2x
FDnet
FDUD291 detector extractor A5Q00003585
FDUD292 detector test extractor A5Q00003357
FDUL221 line tester A5Q00004397
