2-1
C7-621 / C7-621 AS-i Control Systems
C79000-G7076-C621-01
Installing and Preparing the C7
Section Description Page
2.1 Components and Accessories of the C7 2-2
2.2 Installing a C7 2-3
2.3 Location of the C7 2-6
2.4 Electrical Installation and Pinouts 2-7
2.5 Guidelines for Trouble-Free Installation 2-13
2.6 Connecting Up Cables 2-15
2.7 Connector Key Inserts 2-16
2.8 Contrast 2-17
2.9 I/O Expansion with the IM 621 2-18
2.10 Memory Reset on the C7 2-20
2.11 Status and Error LEDs on the C7 2-23
2.12 Clocks on the C7 2-24
