7-1
C7-621 / C7-621 AS-i Control Systems
C79000-G7076-C621-01
C7-621 Analog I/Os
Section Description Page
7.1 Connecting Sensors to Analog Inputs 7-2
7.1.1 Connecting Voltage and Current Sensors 7-5
7.2 Connecting Loads/Actuators to the Analog Output 7-7
7.3 Analog Input 7-10
7.3.1 Properties and Technical Data of the Analog Input 7-11
7.4 Analog Output 7-15
It is not possible to include the C7 in an ungrounded configuration.
Note
The information in this section applies only to the C7-621. The C7-621 AS-i
does not have analog I/Os.
Chapter
Overview
Ungrounded
Configuration
7
