C7-621 / C7-621 AS-i Control Systems
C79000-G7076-C621-01
124.0...125.7
45 67
Slot number
Modules
IM 621
Digital address
128...135
Analog address
Figure 2-14 Maximum Configuration with a C7-621
56 78
Slot number
Modules
IM 621
Figure 2-15 Maximum Configuration for a C7-621 AS-i
