Technical specifications
6.1 Technical specifications
Digital output module DQ 8x24VDC/0.5A SNK BA (6ES7132-6BF61-0AA0)
22 Manual, 09/2017, A5E32855878-AB
Article number
6ES7132-6BF61-0AA0
Output voltage
Rated value (DC)
24 V
Power loss
Power loss, typ.
1.5 W
Address area
Address space per module
• Outputs
1 byte
Hardware configuration
Automatic encoding
Yes
• Mechanical coding element
Yes
Digital outputs
Type of digital output
Source output (PNP, current-sourcing)
Number of digital outputs
8
Current-sinking
Yes
Short-circuit protection
Yes
• Response threshold, typ.
1.5 A
Limitation of inductive shutdown voltage to
Typ. 47 V
Controlling a digital input
Yes
Switching capacity of the outputs
• with resistive load, max.
0.5 A
• on lamp load, max.
5 W
Load resistance range
• lower limit
48 Ω
• upper limit
3 400 Ω
Output current
• for signal "1" rated value
0.5 A
• for signal "1" permissible range, max.
0.5 A
• for signal "0" residual current, max.
5 µA
Output delay with resistive load
• "0" to "1", max.
300 µs
• "1" to "0", max.
600 µs
Parallel switching of two outputs
• for uprating
No
• for redundant control of a load
Yes
