Technical specifications
6.1 Technical specifications
Digital output module DQ 8x24VDC/0.5A SNK BA (6ES7132-6BF61-0AA0)
Manual, 09/2017, A5E32855878-AB
23
Article number
6ES7132-6BF61-0AA0
Switching frequency
with resistive load, max.
100 Hz
with inductive load, max.
0.5 Hz
on lamp load, max.
10 Hz
Total current of the outputs
Current per channel, max.
0.5 A
Current per module, max.
4 A
Total current of the outputs (per module)
horizontal installation
up to 60 °C, max.
4 A
vertical installation
up to 50 °C, max.
4 A; in all other mounting positions
Cable length
shielded, max.
1 000 m
unshielded, max.
600 m
Isochronous mode
Isochronous operation (application synchro-
nized up to terminal)
No
Interrupts/diagnostics/status information
Diagnostics function
Yes
Substitute values connectable
Yes
Alarms
Diagnostic alarm
Yes
Diagnostic messages
Monitoring the supply voltage
Yes
Wire-break
No
Short-circuit
No
Diagnostics indication LED
Monitoring of the supply voltage (PWR-
LED)
Yes; green PWR LED
Channel status display
Yes; Green LED
for channel diagnostics
No
for module diagnostics
Yes; green/red DIAG LED
Potential separation
Potential separation channels
between the channels
No
between the channels and backplane bus
Yes
