Parameter data record
A.1 Parameter assignment and structure of parameter data record
Digital output module DQ 8x24VDC/0.5A SNK BA (6ES7132-6BF61-0AA0)
28 Manual, 09/2017, A5E32855878-AB
Error transferring the data record
The module always checks all the values of the transferred data record. Only if all the values
were transferred without errors does the module apply the values from the data record.
The WRREC instruction for writing data records returns corresponding error codes when
errors occur in the STATUS parameter. (See also the description of the "STATUS"
parameter in the STEP 7 online help).
The following table shows the module-specific error codes and their meaning for the
parameter data record 128.
Error code in STATUS parameter
(hexadecimal)
DF 80 B0 xx Number of the data record un-
known.
Enter a valid number for the data record.
Length of the data record incorrect.
Enter a valid value for the data record length.
DF 80 B2 xx Slot invalid or cannot be accessed.
• Check the station whether the module is
plugged or drawn.
• Check the assigned values for the pa-
rameters of the WRREC instruction.
DF 80 E0 xx Wrong version or error in the
Correct the version, length and number of
DF 80 E1 06 Invalid coding for substitute value
Check the parameters of the module.
