Configuring And Operating The SIMATIC Field PG P4
3-14
SIMATIC Field PG P4 Manual
A5E00180080-04
Caution
Ensure that the used monitor is suitable for the set resolution and refresh rate.
Connecting Devices to the USB Interface 2.0
You can connect USB devices (mouse, keyboard or printer) to the USB 2.0
interface connector.
1. Open the port cover on the rear of the device.
2. Plug the USB device cable into the USB interface.
The Plug and Play operating system recognizes the device and makes it available.
If you wish to connect more than two USB devices you must use a HUB. Both
interfaces are designed for use as high current USB 2.0 (500 mA) devices. They
may not be used simultaneously for high current (refer to the Appendix B,
Technical Data).
USB connector
USB connector
Fig. 3-6 USB connectors
Using a Mouse
You can connect a USB mouse parallel to the Touchpad.
