Configuring the SIMATIC Field PG P4
5-14
SIMATIC Field PG P4 Manual
A5E00180080-04
5.3 The Advanced Menu
Menu Structure
PhoenixBIOS Setup Utility
Item Specific Help
Installed O/S:
ESC Exit
Reset Configuration Data:
Select Item
Select Menu
+ / –
Select
Change Values
Sub-Menu
F9
F10
Setup Defaults
Save and Exit
IRQ Resource Exclusion
Serial port A: [Auto]
S5 TTY port: [Enabled]
[ No ]
Select the operating
system installed
on your system which
you will use most
commonly.
Note: An incorrect
setting can cause
some operating
systems to display
unexpected behavior.
Enter
Help
F1
Security Power Boot Version ExitMain
[ WinXP/2000 ]
Local Bus IDE adapter: [Primary & Secondary]
Advanced
Legacy USB Support: [Disabled]
Parallel port: [Disabled]
Mode: [Bi-directional]
Base I/O address: [378]
Interrupt: [IRQ 7]
Fig. 5-9 ”Advanced” Menu
Settings in the Advanced Menu
Installed O/S Plug & play means that all modules are automatically detected
and installed, providing they support the Plug&Play functionality.
[other] BIOS handles the entire Plug&Play capability, default
configuration
[Win95] The operating system handles a part of the Plug& Play
[Win98] functions
[WinXP/2000]
Reset Configuration
Data
[Yes] All installations under Plug&Play are deleted and
reconfiguration is triggered the next time the system
boots. The entry is then reset to [No]. System
components that do not support Plug&Play have to be
entered manually.
[No] The Plug&Play system components are initialized
after the next system start.
Serial port A Configure Serial Port A with the options:
[Disabled] No configuaration
[Enabled] User configuration
[Auto] BIOS or OS chooses confuguration.
