Siemens SIMATIC Field PG P4 User Manual

Configuring the SIMATIC Field PG P4
5-5
SIMATIC Field PG P4 Manual
A5E00180080-04
5.2 The Main Menu
PhoenixBIOS Setup Utility
Item Specific Help
System Time:
ESC Exit
<Tab>, <Shift-Tab>, or
System Date:
Select Item
Select Menu
+ / –
Select
Change Values
Sub-Menu
F9
F10
Setup Defaults
Save and Exit
<Enter> selects field.
Diskette A: [1,44 MB 3 1/2”]
Primary Master [10056MB]
Primary Slave [None]
Memory Cache:
Boot Options
Keyboard Features
[Write Back]
Hardware Options
System Memory:
Extended Memory:
Secondary Master [CD-ROM]
Secondary Slave [None]
[ 02/06/2003 ]
640 KB
128511 KB
Example:
Hour/Minute/Second
Month/Day/Year
Enter
Help
F1
Advanced Security Power Boot Version ExitMain
[ 15:35:32 ]
Selectable
submenu
Fig. 5-2 Main SETUP Menu (sample)
Settings in the Main Menu
In the Main menu, you can move upwards and downwards using the cursor keys
[↑] and [↓] to select the following system parameters:
Field Meaning
System Time For viewing and setting the current time
System Date For viewing and setting the current date
Diskette A Type of built-in floppy disk drive
Memory Cache For setting the cache options
By submenus
Primary Master Type of built-in drives
Secondary Master Type of built-in drives
Boot Options For setting boot options
Keyboard
Features
For setting keyboard-interface options (e. g. NUM Lock, Typematic
Rate)
Hardware Options For setting PG hardware options
