3.14 Ethernet (RJ45 Ethernet Interface)
Networking Field PG P4 via RJ45 Ethernet Interface
The RJ45 Ethernet interface is a Twisted-Pair (TP) Interface for data transfer rates
of 10/100 Mbaud. This on-board interface is compatible with Intel pro/100+ PCI
Adapters.
The Plug & Play interface is automatically recognized in Windows. Protocols are
configured in the Windows system control.
Notice
A Class 5 Ethernet cable is required for operation with 100 Mbaud. Use a suitable
cable material depending on the length of the cable.
