Configuring the SIMATIC Field PG P4
5-12
SIMATIC Field PG P4 Manual
A5E00180080-04
“Hardware Options” Field
The following submenu appears when you select the “Hardware Options” field in
the main menu:
PhoenixBIOS Setup Utility
Item Specific Help
PCI – MPI / DP:
ESC Exit
Select Item
Select Menu
+ / –
Select
Change Values
Sub-Menu
F9
F10
Setup Defaults
Save and Exit
Programming interface: [Enabled]
Cardbus / PCMCIA Slot:
Enter
Help
F1
Main
[ Enabled ]
Hardware Options
Onboard Ethernet
[Enabled]
[Enabled]
Enable or disable the
PCI - Multi Point
Interface (MPI/DP).
Ethernet Address
08000624E1CB
CRT / LCD selection: [Simultan Auto]
Frame Buffer Size: [32MB]
Touchpad
[Auto Detect]
LAN Remote Boot:
[Disabled]
Also, this item
Enables / Disables the
SIMATIC programming
interface.
LCD-Screensize:
[Expanded]
Onboard Audio Device
[Enabled]
Fig. 5-8 ”Hardware Options” Submenu
The parameters of the interfaces present on the basic module are set here.
Entry Meaning
PCI - MPI / DP Enables the CP5611 compatible MPI/DP interface.
Programming interface Displays enable or disable status of the SIMATIC Memory Card
Interface. Enable follows the enable of PCI-MPI/DP.
Cardbus / PCMCIA
Slot
[Disabled] Enable Cardbus / PCMCIA-
interface deactivated.
[Enabled] Resources are managed by BIOS PCI
Plug & Play mechanisms.
