Siemens SIMATIC HMI KTP1000 Basic color DP - KTP400 Basic and KTP600 Basic

Technical specifications
8.4 Specifications
Basic Panels
Operating Instructions, 04/2012, A5E02421799-03
133
8.4.3 KTP400 Basic and KTP600 Basic
Weight
KTP400 Basic
mono PN
KTP400 Basic
color PN
KTP600 Basic
mono PN
KTP600 Basic
color DP
KTP600 Basic
color PN
Weight without packaging Approx. 320 g Approx. 340 g Approx. 1070 g
Display
KTP400 Basic
mono PN
KTP400 Basic
color PN
KTP600 Basic
mono PN
KTP600 Basic
color DP
KTP600 Basic
color PN
Type LCD mono FSTN LCD TFT LCD mono FSTN LCD TFT
Active display area 76.8 x 57.6 mm
(3.8")
95 x 53.8 mm
(4.3")
115.2 mm x 86.4 mm
(5.7")
Resolution 320 x 240 pixels 480 x 272 pixels 320 x 240 pixels
Possible colors 4 grayscales 256 4 grayscales 256
Contrast control Yes No Yes No
Brightness control No Yes No No
Backlighting
Half Brightness Life Time
(MTBF
1
)
LED
30,000 h
LED
50,000 h
CCFL
50,000 h
Pixel error class according
to DIN EN ISO 13406-2
- II - II
1
MTBF: Operating hours after which the maximum brightness is reduced by half compared to the original value. MTBF is
increased by using the integrated dimming function, for example, time-controlled via screen saver or centrally via
PROFIenergy.
Input device
KTP400 Basic
mono PN
KTP400 Basic
color PN
KTP600 Basic
mono PN
KTP600 Basic
color DP
KTP600 Basic
color PN
Type Touch screen, analog resistive
Function keys 4 6
Labeling strips Yes
Memory
KTP400 Basic
mono PN
KTP400 Basic
color PN
KTP600 Basic
mono PN
KTP600 Basic
color DP
KTP600 Basic
color PN
Application memory 512 KB
