Overview
1.8 Design of the KTP1000 Basic color PN
Basic Panels
Operating Instructions, 04/2012, A5E02421799-03
19
1.8 Design of the KTP1000 Basic color PN
① Power supply connector ⑦ Rating plate
② PROFINET interface ⑧ Interface name
③ Cutouts for a mounting clamp ⑨ Fixing element
④ Display/touch screen ⑩ Functional earth connection
⑤ Mounting seal ⑪ Guide for labeling strips
⑥ Function keys
