Overview
1.6 Design of the KTP600 Basic mono/color PN
Basic Panels
Operating Instructions, 04/2012, A5E02421799-03
17
1.6 Design of the KTP600 Basic mono/color PN

① Power supply connector ⑥ Function keys
② PROFINET interface ⑦ Rating plate
③ Cutouts for a mounting clamp ⑧ Interface name
④ Display/touch screen ⑨ Guide for a labeling strip
⑤ Mounting seal ⑩ Functional earth connection
