1.12 Accessories
Basic Panels
Operating Instructions, 04/2012, A5E02421799-03
23
1.12 Accessories
Accessories are not included in the product package of the HMI device, but can ordered on
the Internet under Industry Mall (http://mall.automation.siemens.com
).
This section contains the number of accessories available at the time of publication of the
operating instructions.
Converters, adapters and connectors
Name Purpose Order no.
RS 422 to RS 232
converter
Connection of third-party controllers to Basic
Panels DP
6AV6671-8XE00-0AX0
PC/PPI cable Converts RS 422/RS 485 signals to RS 232
signals. Is required for updating the operating
system with reset to factory settings
1
. Can also
be used for the transfer.
6ES7 901-3CB30-0XA0
90 degree elbow
adapter
For RS422/RS485 interface, cable outlet to rear 6AV6671-8XD00-0AX0
USB/PPI cable Converts RS 422/RS 485 signals to USB
signals. Is required for updating the operating
system with reset to factory settings. Can also
be used for the transfer.
6ES7 901-3DB30-0XA0
PROFIBUS connector Recommended PROFIBUS connector with
straight cable outlet
6GK1500-0FC10
PROFINET RJ45
connector "IE FC RJ45
Plug 2x2"
Required for connection of Basic Panels PN to
PROFINET
6GK1901-1BB10-2AA0
1
If the connection is lost during the operating system update, set a lower bit rate. If you use a higher
bit rate, you must use the PC/PPI cable release 3 or higher. The release code is printed on the
cable ("E version 3," for example, corresponds to release 3).
Clamping frame
Name Purpose Order no.
Clamping frame
for 10"/12" Touch
For reinforcement of the mounting cutout for
KTP1000 Basic when material is not thick
enough
6AV6 671-8XS00-0AX0
