SIMATIC IPC847D
22 A5E38018732-AD, 09/2017
Technical specifications of the graphics interfaces
Changes to the following sections of the operating instructions:
Sec. 1.1.4 Characteristics
Sec. 8.4.1 General technical specifications
Sec. 8.5.1.2 Technical features of the motherboard
Resolution, frequency and color depth for the following processors:
● Intel® Core™ i3-4330TE, HD Graphics 4600 (GT2)
● Intel® Core™ i5-4570TE HD Graphics 4600 (GT2)
● Intel® Xeon™ E3-1268L v3 HD Graphics 4600 (GT2)
● Intel® Xeon™ E3-1275L v3 HD Graphics P4600 (GT2)
Resolution
Frequency
Color depth
DisplayPort (DPP)
3840 x 2160 dpi
60 Hz
32-bit
DVI-D 1920 x 1200 dpi 60 Hz 32-bit
VGA
1920 x 1200 dpi
60 Hz
32-bit
● Comparison of NVIDIA NVS315 and NVS300
Specification
NVIDIA NVS315 graphics card (new)
NVIDIA NVS300 graphics card (old)
NVIDIA graphics processor
48 CUDA parallel computing cores
16 CUDA parallel computing cores
Total picture memory
1024 MB
512 MB
Bandwidth of the video
interface
64 bits
Memory bandwidth
14 Gbps
12.6 Gbps
Max. VGA resolution
2048 x 1536 @ 85Hz; color depth 32 bit
Max. DVI resolution
1920 x 1200 @ 60Hz; color depth 32 bit
Max. DP resolution
2560 x 1600 @ 60Hz; color depth 32 bit
Graphics slot
PCI Express 2.0 x16
Form factor
69.37 mm x 167.64 mm (ATX bracket, 1 slot)
Interfaces
2 x DVI-D or 2 x VGA
Max. power rating
19.5 W
17 W
Cooling
Actively with fan
Without fan
Scope of Delivery in the
Configurator
1 x DMS-59 to 2 x DVI-D adapter, 2 x DVI to VGA adapter
Note
•
The fan is monitored with SIMATIC IPC DiagBase as of version 1.5.2 or DiagMonitor software as of version 4.5.2 and
5.x.x (all).
•
The new NVIDIA NVS315 graphics card is compatible with the old NVIDIA NVS300 graphics card regarding their
interfaces.
•
The operating system of the devices have been updated to work with the new NVS315 graphics card.
Customized configuration
•
Users configuring new IPCs with their own Windows system images must update these images with the new drivers
provided on the "Documentation and Drivers" DVD as of 04/2017, or they must use the operating system deri
vative as of
04/2017 as the new basis.
• Users using third-party systems (e.g. Linux, QNX, etc.) should check for compatibility with the new graphics card.
