⑮ 4 digital inputs (X4060)
⑯ Supply of inputs/outputs (X4060)
⑰ Pin assignment
Figure3-1 Connections of PDC600 drive controller with pin assignment
DANGER
Hazardous Voltage
Can Cause Death, Serious Injury, or Property Damage.
Hazardous electrical voltage can cause electric shock, burns and property damage.
Disconnect the system and devices from the supply before commencing work.
References
Note the detailed information on selection of the installation location, mounting position,
ambient temperature, minimum clearances, etc. in the System Manual SIMATIC MICRO-DRIVE
Drive controller PDC (https://support.industry.siemens.com/cs/ww/en/view/109774126).
You can also 󹪝nd information on the topic of "Accessories/spare parts" in the System Manual
SIMATIC MICRO-DRIVE Drive controller PDC.
The SIMATIC MICRO-DRIVE drive system is compatible with motors (Dunkermotoren, ebm-
papst) and connecting cables (Harting, KnorrTec) of proven product partners of Siemens.
This allows you to optimally combine suitable products from proven product partners for
your individual application. You can 󹪝nd more information about the Siemens Product
Partner Program on the Internet (https://new.siemens.com/global/en/company/topic-areas/
partners/product-partners-industry.html).
Interfaces, cable lengths and cable types
The following cable lengths and cable types are permitted for the interfaces.
Table 3-1 Wiring rules for the interfaces
Plug connec‐
tor
Function Maximum cable length Cable type Cable cross-section
X100 Functional ground 0.1m Grounding strap ≥ 4mm
2
X2050 PROFINET Port1 100m Shielded cable, 2x twis‐
ted pair, Cat5
-
X2060 PROFINET Port2 100m Shielded cable, 2x twis‐
ted pair, Cat5
-
Connecting
3.1Terminal assignment
PDC600(F)
20 Equipment Manual, 12/2023, A5E50502703-AB
