Plug connec‐
tor
Function Maximum cable length Cable type Cable cross-section
X4050 Incremental encoder sig‐
nals and supply
10m Shielded
For di󹪜erential wiring,
one twisted pair per sig‐
nal pair
Solid and stranded sup‐
ply cable:
AWG*: 22 to 16 or
0.34mm
2
to 1.5mm
2
Hall sensor signals and
supply
10m Shielded
Encoder and Hall inter‐
face with "All-in-one"
plug-in cable
10m Shielded in "All-in-one" plug-in cable
X4060 I/O, inputs and outputs 20m
• <2m unshielded
• ≥2m shielded
Solid and stranded sup‐
ply cable:
AWG*: 22 to 16 or
0.34mm
2
to 1.5mm
2
For through-wiring for
maximum permissible
terminal currents, use
AWG*16 or 1.5mm
2
.
Supply of inputs/outputs 20m
• <2m unshielded
• ≥2m shielded
X5050 Power supply of power
unit (4L+, 4M)
20m
• <2m unshielded
• ≥2m shielded
Solid and stranded sup‐
ply cable:
AWG*: 20 to 10 or
0.5mm
2
to 4mm
2
Use AWG*10 or 4mm
2
for the recommended cir‐
cuit breaker.
X5051 Connection of external
braking resistor (4R+, 4R-)
2m Unshielded Solid and stranded sup‐
ply cable:
AWG*: 18 to 16 or
1.0mm
2
to 1.5mm
2
X5055 Motor phases 10m Shielded Solid and stranded sup‐
ply cable:
AWG*: 18 to 10 or
1.0mm
2
to 4mm
2
Motor phases with "All-in-
one" plug-in cable
10m Shielded in "All-in-one" plug-in cable
Connecting
3.1Terminal assignment
PDC600(F)
Equipment Manual, 12/2023, A5E50502703-AB 21
