Description of the device
4.2 Accessories
SCALANCE SC-600
Operating Instructions, 10/2021, C79000-G8976-C453-04
25
Pluggable transceiver
WARNING
Use only approved pluggable transceivers
If you use pluggable transceivers that have not been approved by Siemens AG, there is
no guarantee that the device will function according to its specifications.
If you use unapproved pluggable transceivers, this can lead to the following problems:
• Damage to the device
• Loss of the approvals
• Violation of the EMC regulations
Use only approved pluggable transceivers.
Note
Plugging and pulling during operation
You can plug and pull pluggable transceivers with the device in operation.
SFP transceiver
Table 4- 1 Pluggable transceiver SFP 100 Mbps (not for SCALANCE SC62x-2C)
1 x 100 Mbps, LC port optical for glass FO
cable (multimode), up to max. 5 km
1 x 100 Mbps, SC port optical, for glass FO
cable (multimode), up to max. 5 km, varnished
1 x 100 Mbps LC port optical for glass FO
cable (single mode) up to max. 26 km
1 x 100 Mbps LC port optical for glass FO
cable (single mode) up to max. 26 km, coated
1 x 100 Mbps LC port optical for glass FO
cable (single mode) up to max. 70 km
1 x 100 Mbps LC port optical for glass FO
cable (single mode) up to max. 200 km
Table 4- 2 Pluggable transceiver SFP 1000 Mbps
1 x 1000 Mbps, LC port optical for glass FO
cable (multimode), up to max. 750 m
1 x 1000 Mbps, LC port optical, for glass FO
cable (multimode), up to max. 750 m,
1 x 1000 Mbps, LC port optical for glass FO
cable (multimode), up to max. 2 km
