Siemens SIMATIC NET SCALANCE SC-600 User Manual

Connecting
6.5 Digital input
SCALANCE SC-600
Operating Instructions, 10/2021, C79000-G8976-C453-04
59
Position and assignment
Figure 6-3 Position and assignment of the digital input based on the example of the SCALANCE
SC646-2C.
Contact
Assignment
DI
-30 to +30 VDC
M
Ground
