Technical specifications
8.1 Technical specifications of the SCALANCE SC-600
SCALANCE SC-600
68 Operating Instructions, 10/2021, C79000-G8976-C453-04
Technical specifications
Design
Terminal block, 2 terminals
Property
Isolated from electronics
Rated voltage
24 VDC safety extra-low voltage (SELV)
For state "0":
-30 to 3 VDC
For state "1":
13 to 30 VDC
Maximum input current
8 mA
Maximum cable length
< 3 m
Permitted ambient conditions
Ambient temperature
When operating with
pluggable transceivers of the
types:
• SFP991-1/1 (C)/1LD/1LD
(C)
• SFP992-1/1 (C)/1LD/1LD
(C)
up to 2000 m
During operation with the rack installed
horizontally:
-40 ºC to +65 ºC
During operation with the rack installed
vertically:
-40 ºC to +60 ºC
When operating with
pluggable transceivers of the
types:
• SFP991-1LH+/1ELH200
• SFP992-
1+/1LD+/1LH/1LH+/1EL
H
• SFP992-
1BXMT/1BXMR/1BX10T/1
BX10R
up to 2000 m
During operation with the rack installed
horizontally:
-40 ºC to +60 ºC
During operation with the rack installed
vertically:
-40 ºC to +50 ºC
During LAN operation with
RJ45 connector up to 2000 m
During operation with the rack installed
horizontally:
-40 ºC to +70 ºC
During operation with the rack installed
vertically:
-40 ºC to +65 ºC
With operation between
2000 m and 3000 m
The maximum ambient temperature is reduced
by 5 ºC
With operation between
3000 m and 4000 m
The maximum ambient temperature is reduced
by 10°C
Storage
-40 ºC to +85 ºC
Transportation
-40 ºC to +85 ºC
Relative humidity
Operation at 25 ℃
≤ 95 % no condensation
Housing, dimensions and weight
Design
compact
Housing material
Basic housing
Die cast aluminum, powder coated
Front cover
Polycarbonate (PC-GF10)
Degree of protection
IP20
