Siemens SIMATIC PCS 7 System Manual

Technical data
16.1 Technical specifications of CPU 410-5H; (6ES7410-5HX08-0AB0)
CPU 410 Process Automation/CPU 410 SMART
System Manual, 05/2017, A5E31622160-AC
259
Article number
6ES7410-5HX08-0AB0
– Updating time
250 µs to 512 ms, minimum value depends on
the number of configured user data and the con-
figured single or redundant mode
Address area
– Inputs, max.
8 kbyte; up to 3 800 IOs (channels)
– Outputs, max.
8 kbyte; up to 3 800 IOs (channels)
– User data consistency, max.
1 024 byte
Open IE communication
• Number of connections, max.
118
• Local port numbers used at the system end
0, 20, 21, 25, 102, 135, 161, 34962, 34963,
34964, 65532, 65533, 65534, 65535
• Keep-alive function, supported
Yes
3. Interface
Interface type
PROFINET
Physics
Ethernet RJ45
Isolated
Yes
automatic detection of transmission rate
Yes; Autosensing
Autonegotiation
Yes
Autocrossing
Yes
System redundancy
Yes
Redundant subnetworks
Yes
Number of connection resources
120
Interface types
• Number of ports
2
• integrated switch
Yes
Media redundancy
• supported
Yes
• Switchover time on line break, typ.
< 200 ms
• Number of stations in the ring, max.
50
Functionality
• PROFINET IO Controller
Yes
• PROFINET IO Device
No
• PROFINET CBA
No
• Open IE communication
Yes
• Web server
No
PROFINET IO Controller
• Transmission rate, max.
100 Mbit/s
Services
– PG/OP communication
Yes
