Technical data
16.1 Technical specifications of CPU 410-5H; (6ES7410-5HX08-0AB0)
CPU 410 Process Automation/CPU 410 SMART
System Manual, 05/2017, A5E31622160-AC
261
Article number
6ES7410-5HX08-0AB0
Protocols (Ethernet)
• TCP/IP
Yes
Further protocols
• Foundation Fieldbus
Yes; via DP/FF Link
• MODBUS
Yes; Via add-on
Communication functions
PG/OP communication
Yes
• Number of connectable OPs without mes-
sage processing
119
• Number of connectable OPs with message
processing
119; When using Alarm_S/SQ and Alarm_D/DQ
Data record routing
Yes
S7 routing
Yes
S7 communication
• supported
Yes
• as server
Yes
• as client
Yes
• User data per job, max.
64 kbyte
• User data per job (of which consistent),
max.
462 byte; 1 variable
Open IE communication
• TCP/IP
Yes; via integrated PROFINET interface and
loadable FBs
– Number of connections, max.
118
– Data length, max.
32 kbyte
– several passive connections per port,
supported
Yes
• ISO-on-TCP (RFC1006)
Yes; Via integrated PROFINET interface or CP
443-1 and loadable FBs
– Number of connections, max.
118
– Data length, max.
32 kbyte; 1452 bytes via CP 443-1 Adv.
• UDP
Yes; via integrated PROFINET interface and
loadable FBs
– Number of connections, max.
118
– Data length, max.
1 472 byte
Number of connections
• overall
120
S7 message functions
Number of login stations for message func-
tions, max.
119; Max. 119 with Alarm_S and Alarm_D (OPs);
max. 12 with Alarm_8 and Alarm_P (e.g. WinCC)
