Siemens SIMATIC PCS 7 Manual

1-3
Connecting TM I/O to PCS 7
C79000-G8076-C710-04
All connection and display elements of the TPM 478-2 interface module are
mounted on the front panel of the module, see Figure 1-2.
LED displays
connection
TPM 478-2
connection
connection
Connecting cable
+
SV: 5 V-Bus
-
I/O bus
I/O bus A
I/O bus B
FEA
PA A
PA B
RUN
X2
Figure 1-2 Arrangement of the connections and display modules of the TPM 478-2
interface module
Elements of
TPM 478-2
Hardware structure
