Installation
4.2 Technical data of the telescopic rails
SIMATIC Rack PC 840 V2
4-2 Getting Started, Edition 04/2004, A5E00248069-02
Caution
Danger of bodily harm!
It is not permitted to mount the device only on the 19" brackets of the front panel.
Caution
Remove the bonded stands when mounting the device on telescopic rails. Restricted
technical specifications for drives in the front drive bay apply for this type of installation.
For details, refer to the technical data or retrofitting instructions.
4.2 Technical data of the telescopic rails
Ultimate load per pair Minimum 30 kg
Full extraction length Minimum 470 mm
Rail thickness maximum 9.7 mm
Fixing screws M5 x 6 mm
