Typical areas of application are:
•
Multi-axis machines (e.g. printing and paper machines)
•
High-performance applications with short machine cycles (e.g. packaging machines and
handling applications)
•
Compact machines in which there is limited room for the controller and drive system (e.g.
control cabinets in the machine base)
•
Distributed control and drive concepts
•
Synchronization of multiple SIMATIC Drive Controller s using cross-PLC synchronous
operation
•
Safe monitoring of motion
SIMATIC Drive Controller performance classes
The SIMATIC Drive Controller contains a failsafe CPU from the SIMATIC S7-1500 family and a
SINAMICS S120 drive control. Two performance classes are available.
Table 3-1Overview of performance classes
Performance class SIMATIC Drive Controller Article number
Small to mid-range applications CPU 1504D TF 6ES7615-4DF10-0AB0
High-performance applications CPU 1507D TF 6ES7615-7DF10-0AB0
Performance features of the CPUs
The SIMATIC Drive Controller s differ in terms of the integrated CPU. The CPUs can be used for
lower and mid-range applications all the way to the high-end range of machine and plant
automation. The following table shows key performance characteristics of the SIMATIC Drive
Controllers.
Table 3-2Overview of SIMATIC Drive Controller performance features
Feature 1504D TF 1507D TF
Code work memory, max. 4MB 15MB
Data work memory, max. 6MB 40MB
Retentive data area
(including timers, counters, bit memor
ies)
768KB 768KB
Load memory/mass storage, max. 32 GB
(with SIMATIC Memory Card)
32 GB
(with SIMATIC Memory Card)
I/O address area, max. 32/32KB 32/32KB
Integrated interfaces 1 x PROFINET IO IRT (3-port switch)
1 x PROFINET IO RT
1 x PROFINET basic services (1000 Mbps)
1 x PROFIBUS DP
2 x USB 3.0
1)
4 x DRIVE-CLiQ
1 x PROFINET IO IRT (3-port switch)
1 x PROFINET IO RT
1 x PROFINET basic services (1000 Mbps)
1 x PROFIBUS DP
2 x USB 3.0
1)
4 x DRIVE-CLiQ
SINAMICS Integrated On basis of CU320-2 On basis of CU320-2
Integrated inputs and outputs
(onboard I/O)
CPU: 8 DI/DQ
SINAMICS Integrated: 12 DI, 8 DI/DQ
CPU: 8 DI/DQ
SINAMICS Integrated: 12 DI, 8 DI/DQ
18
SIMATIC Drive Controller
Equipment Manual, 11/2022, A5E46600370-AC
Product overview
3.2 Application range
