Technical specifications
7
7.1
Technical specifications of the CP
Table 7- 1 Technical specifications of the CP 443-1 OPC UA
Technical specifications
Article number
• CP 443-1 OPC UA • 6GK7 443-1UX00-0XE0
Attachment to Industrial Ethernet
Amount
1 x Ethernet interface
Design
Connector
1 x RJ-45 jack
Transmission speed 10/100/1000 Mbps
Permitted cable lengths (Ethernet)
Alternative combinations per length range *
0 ... 55 m
• Max. 55 m IE TP Torsion Cable with IE FC RJ45 Plug 180
• Max. 45 m IE TP Torsion Cable with IE FC RJ45 + 10 m TP Cord via
IE FC RJ45 Outlet
0 ... 85 m
• Max. 85 m IE FC TP Marine/Trailing/Flexible/FRNC/Festoon/Food Cable with
IE FC RJ45 Plug 180
• Max. 75 m IE FC TP Marine/Trailing/Flexible/FRNC/Festoon/Food Cable +
10 m TP Cord via IE FC RJ45 Outlet
0 ... 100 m
• Max. 100 m IE FC TP Standard Cable with IE FC RJ45 Plug 180
• Max. 90 m IE FC TP Standard Cable + 10 m TP Cord via IE FC RJ45 Outlet
Electrical data
Power supply
via S7 backplane bus
5 V
Current consumption
From backplane bus
1.8 A
Power dissipation
7.25 W
Permitted ambient conditions
Ambient temperature
During operation
0 °C to +60 °C
During storage
-40 °C to +70 °C
During transportation
-40 °C to +70 °C
Relative humidity
During operation
≤ 95 % at 25 °C, no condensation
Operating altitude
≤ 2,000 m above sea level
Contaminant concentration
Acc. to ISA-S71.04 severity level G1, G2, G3
Design, dimensions and weight
Module format Compact module for S7-400, single width
Degree of protection
IP20
Weight
Approx. 700 g
