03/2013 3 Setting up functions
3.4 Fault services
© Siemens AG 2006-2013 All Rights Reserved
SINUMERIK Integrate AMB, AMC, AMM, Function Manual (FH) - 03/2013
3-153
Function Description Type
Initiate trigger if
a measurement
Select type of limit value
• "Reaches or exceeds the critical limit":
If at least one critical limit was reached or
exceeded.
• "Reaches or exceeds the warning limit or
critical limit"
If at least one warning limit was reached
or exceeded (exceeding the critical limit is
also possible in this case).
• "Reaches the warning limit, but not the
critical limit":
If only the warning limit was reached or
exceeded, and the critical limit was not
reached.
SELECTION
1 of 3
Measurement
series
1-n of n
Display and selection of the existing
measurement series for the trigger
DISPLAY
SELECTION
