2 Machine information 03/2013
2.2 Variable monitors – time Series – measurements and measurement series
© Siemens AG 2006-2013 All Rights Reserved
2-44 SINUMERIK Integrate AMB, AMC, AMM, Function Manual (FH) - 03/2013
Context menu of the time series diagram
If you point the cursor to an individual measuring point within the time series in the
diagram and right-click, a context menu containing actions relating to that
measuring point appears. The functions executed via the context menu relate to
either the entire measurement range to which the measuring point belongs (i.e. the
measurement range and the measurement), or simply the measurement
represented by the data point.
Function
Measurement series comment Displays the measurement series comment. This
can be changed and saved.
Measurement / measurement
series parameters
Supplementary conditions for
measurement
Characteristic/limit values
measurement
