5.5 SIMODRIVE POSMO A functions
5-180
 Siemens AG 2013 All Rights Reserved
SIMODRIVE POSMO A User Manual (POS1) – 08/2013 Edition
5.5.7 Changeover, metric/inch
When changing over between mm and inch and vice versa, all existing
values, dependent on length measurements, are automatically
changed.
All of the following inputs and outputs are handled in the new dimen-
sion units.
P4 Dimension unit
5.5.8 Reversing the control sense (from SW 1.3)
Before SW 1.3 the following applies:
The direction of rotation of the motor shaft depends on whether it tra-
verses in the positive or negative direction and cannot be changed.
From SW 1.3, the following applies:
The direction of rotation of the motor shaft can be set as required, depen-
dent on whether traversing in the positive or negative direction using P3.
Table 5-8 Traversing and direction of rotation of the motor shaft
Traversing direction
Rotation of the motor shaft
when viewing the motor shaft drive out end
P3 = positive P3 = negative
(from SW 1.3)
Traversing in the posi-
tive direction
Clockwise Counter–clockwise
Traversing in the nega-
tive direction
Counter–clockwise Clockwise
P3 Gearbox ratio
Description
Parameter
(refer to Chapter
5.6.2)
Description
Parameter
(refer to Chapter
5.6.2)
5 Description of the Functions
02.9904.01
