Siemens SIMOTICS M-1PH8 Commissioning Instructions

Converter data sheets and characteristics
4.1 Forced ventilation
Commissioning instructions for SIMOTICS M-1PH8 Premium Performance
Commissioning Manual, 10/2014, 610.40106.40
51
1PH8087-1_V0/1, operation on Booksize Combi with 300% overload
Motor/DRIVE CLiQ data
Booksize Combi with 300% overload
400 V
480 V
Rated motor voltage
p304
296
296
Rated motor voltage
p305
19.0
19.0
Rated motor power p307 6.5 6.5
Rated motor power factor
p308
0.72
0.72
Rated motor frequency p310 403.3 403.3
Rated motor speed
p311
12,000
12,000
Motor rated magnetizing current/short-circuit
current
p320 10.6 10.6
Maximum motor speed
p322
24,000
24,000
Motor stall torque correction factor
p326
70
70
Type of motor cooling
p335
1
1
Motor moment of inertia
p341
0.0094
0.0094
Motor weight (for thermal motor type)
p344
37
37
Speed at the start of field weakening Vdc =
600 V
p348 11,544 11,544
Motor stator resistance, cold
p350
0.07727
0.07727
Cold motor rotor resistance/damper re-
sistance d-axis
p354 0.064 0.064
Motor stator leakage inductance
p356
0.200
0.200
Motor rotor leakage inductance/damping
inductance d axis
p358 0.499 0.499
Motor magnetizing inductance/magnetizing
inductance d axis, saturated
p360 6.642 6.642
Mot_temp_mod 2/KTY warning threshold
p604
150
150
Mot_temp_mod 1/2 threshold p605 170 170
