Par. No.
Name
Min
Max
Factory
Setting
Unit
Data
type
Effective
Can be
changed
p29300 Digital input forced sig-
nals
0 127 0 - U32 IM T, U
Description:
assignment signals are forced to be high. 7 bits in total.
• Bit 0: SON
• Bit 1: CWL
• Bit 2: CCWL
• Bit 3: TLIM1
• Bit 4: SPD1
• Bit 5: TSET
• Bit 6: EMGS
If one or more bits are set to be high, the corresponding input signals are forced to be logical high signals.
Note:
The drive unit displays the value in hex format. To know the logic (high/low) assignment to each bit, you
must convert the hex number to the binary number, for example, FF (hex) = 11111111 (bin).
p29301[0..
.3]
Digital input 1 assignment
0
28
1
-
I16
IM
T
Description:
Defines the function of digital input signal DI1 (PTI mode)
• 1: SON
• 2: RESET
• 3: CWL
• 4: CCWL
• 5: G-CHANGE
• 6: P-TRG
• 7: CLR
• 8: EGEAR1
• 9: EGEAR2
• 10: TLIM1
• 11: TLIM2
• 12: CWE
• 13: CCWE
• 14: ZSCLAMP
• 15: SPD1
• 16: SPD2
• 17: SPD3
• 18: TSET
• 19: SLIM1
• 20: SLIM2
• 21: POS1
• 22: POS2
• 23: POS3
• 24: REF
• 25: SREF
• 26: STEPF
• 27: STEPB
•
28: STEPH
Index:
• [0]: DI1 for control mode 0
• [1]: DI1 for control mode 1
• [2]: DI1 for control mode 2
•
[3]: DI1 for control mode 3
