Siemens SIMOTICS S-1FL6 Getting Started

Getting Started
102 A5E36037886-003, 04/2017
Par. No.
Name
Min
Max
Factory
Setting
Unit
Data
type
Effective
Can be
changed
p29302[0..
.3]
Digital input 2 assignment
0
28
2
-
I16
IM
T
Description: Defines the function of digital input signal DI2
Index:
• [0]: DI2 for control mode 0
• [1]: DI2 for control mode 1
• [2]: DI2 for control mode 2
•
[3]: DI2 for control mode 3
p29303[0..
.3]
Digital input 3 assignment
0
28
3
-
I16
IM
T
Description: Defines the function of digital input signal DI3
Index:
• [0]: DI3 for control mode 0
• [1]: DI3 for control mode 1
• [2]: DI3 for control mode 2
• [3]: DI3 for control mode 3
p29304[0..
.3]
Digital input 4 assignment
0
28
4
-
I16
IM
T
Description: Defines the function of digital input signal DI4
Index:
• [0]: DI4 for control mode 0
• [1]: DI4 for control mode 1
• [2]: DI4 for control mode 2
•
[3]: DI4 for control mode 3
p29305[0..
.3]
Digital input 5 assignment
0
28
[0] 5; [1]
5; [2]
12; [3]
12
-
I16
IM
T
Description: Defines the function of digital input signal DI5
Index:
• [0]: DI5 for control mode 0
• [1]: DI5 for control mode 1
• [2]: DI5 for control mode 2
•
[3]: DI5 for control mode 3
p29306[0..
.3]
Digital input 6 assignment 0 28 [0] 6; [1]
6; [2]
13; [3]
13
- I16 IM T
Description: Defines the function of digital input signal DI6
Index:
• [0]: DI6 for control mode 0
• [1]: DI6 for control mode 1
• [2]: DI6 for control mode 2
•
[3]: DI6 for control mode 3
p29307[0..
.3]
Digital input 7 assignment 0 28 [0] 7; [1]
21; [2]
15; [3]
18
- I16 IM T
Description: Defines the function of digital input signal DI7
Index:
• [0]: DI7 for control mode 0
• [1]: DI7 for control mode 1
• [2]: DI7 for control mode 2
•
[3]: DI7 for control mode 3
