Par. No.
Name
Min
Max
Factory
Setting
Unit
Data
type
Effective
Can be
changed
p29308[0..
.3]
Digital input 8 assignment
0
28
[0] 10;
[1] 22;
[2] 16;
[3] 19
-
I16
IM
T
Description: Defines the function of digital input signal DI8
Index:
• [0]: DI8 for control mode 0
• [1]: DI8 for control mode 1
• [2]: DI8 for control mode 2
•
[3]: DI8 for control mode 3
p29330
Digital output 1 assign-
ment
1
15
1
-
I16
IM
T
Description: Defines the function of digital output signal DO1
• 1: RDY
• 2: FAULT
• 3: INP
• 4: ZSP
• 5: SPDR
• 6: TLR
• 7: SPLR
• 8: MBR
• 9: OLL
• 10: WARNING1
• 11: WARNING2
• 12: REFOK
• 13: CM_STA
• 14: RDY_ON
•
15: STO_EP
p29331 Digital output 2 assign-
ment
1 15 2 - I16 IM T
Description: Defines the function of digital output signal DO2
p29332 Digital output 3 assign-
ment
1 15 3 - I16 IM T
Description: Defines the function of digital output signal DO3
p29333 Digital output 4 assign-
ment
1 15 5 - I16 IM T
Description: Defines the function of digital output signal DO4
p29334
Digital output 5 assign-
ment
1
15
6
-
I16
IM
T
Description: Defines the function of digital output signal DO5
p29335 Digital output 6 assign-
ment
1 15 8 - I16 IM T
Description: Defines the function of digital output signal DO6
p29340
Warning 1 assigned for
digital output
1
6
1
-
U16
IM
T
Description:
Defines conditions for WRN1.
• 1: Motor overload protection warning: 85% of overload threshold has been reached.
• 2: Holding brake power overload warning: 85% of overload threshold has been reached.
• 3: Fan warning: fan has stopped for more than 1 s.
• 4: Encoder warning
• 5: Motor overtemperature warning: 85% of overtemperature threshold has been reached.
•
6: Capacitor service life warning: The capacitor has reached its expiry, so replace it.
