Correctly connecting temperature sensors
NOTICE
Motor destroyed as a result of overtemperature
The motor can be destroyed as a result of overtemperature if you do not correctly connect the
temperature sensors.
• When connecting temperature sensor cables with open conductor ends, pay attention to
the correct assignment of conductor colors.
Note
Observe the polarity
Carefully note the polarity when connecting the KTY.
PTC elements must be evaluated for thermal motor protection.
Table 6-6 Conductor assignment for Temp-S and Temp-F temperature sensor cables
Core assignment for motors with signal cable without con‐
nector
Sensor contact for 1FW6
White -1R2: -KTY or Pt1000
Brown +1R1: +KTY or Pt1000
Green 1TP1: PTC130°C
Yellow 1TP2: PTC130°C
Gray 2TP1: PTC150°C *)
Pink 2TP2: PTC150°C *)
green/yellow PE
*) PTC150°C, optional in conjunction with KTY84
Connection
6.2Electrical connection
1FW6 built-in torque motors
102 Operating Instructions, 09/2022, A5E52220812B AA
