Technical feature Version
Connection, electrical Cable outlet
• Axial
• Radial towards the outside
– Not for 1FW6050 and 1FW6060
• Tangential
– Not for motors with single cores
Connection types
• Permanently connected power and signal cables
– Open wire ends
– Length: 2m
• Permanently connected power cables with single cores and signal cables
– Open wire ends
– Length: 1m
• Permanently connected power and signal cables
– Prefabricated with connectors
– Length: 0.5m
– Not for motors with single cores
Motor feeder cables Power and signal cables
• MOTION-CONNECT 800PLUS, type 6FX8
Torque ripple ≤ 1.5% M
0
Description
3.1Technical features and ambient conditions
1FW6 built-in torque motors
Operating Instructions, 09/2022, A5E52220812B AA 33
