Page #69 background imageLoading...
Page #69 background image
WARNING
Electric shock caused by defective cables
Defective connection cables can cause an electric shock and/or material damage, e.g. by 󹪝re.
When installing the motor, make sure that the connection cables
are not damaged
are not under tension
cannot come into contact with any rotating parts
Note the permissible bending radii (see "Important data for 1FW6 cables (Page94)").
Do not hold a motor by its cables.
Do not pull the motor cables.
WARNING
Electrical shock hazard
Every movement of the rotor compared with the stator and vice versa induces a voltage at the
stator power connections.
When the motor is switched on, the stator power connections are also at a speci󹪝c voltage.
If you use defective cable ports, you could su󹪜er an electric shock.
Only mount and remove the electrical components if you are quali󹪝ed to do so.
Any work carried out at the motor must always be done with the system in a no-voltage
condition.
Do not touch the cable ports. Correctly connect the stator power connections, or insulate
them properly.
Do not disconnect the power connections when the stator is under voltage (live).
Only use the speci󹪝c power cables intended for the purpose.
First connect the protective conductor (PE).
Connect the cable shield through a wide area.
First connect the power cable to the stator before you connect the power cable to the
inverter.
First disconnect the connection to the inverter before you disconnect the power connection
to the stator.
Disconnect the protective conductor PE last.
CAUTION
Risk of crushing when the rotor is installed
There is a risk of crushing when the rotor of an installed torque motor rotates!
Wear safety gloves.
Take extreme care when performing any work.
Installation
5.1Safety instructions relating to installation
1FW6 built-in torque motors
Operating Instructions, 09/2022, A5E52220812B AA 67
