SIMOTION C
Operating Instructions, 02/2012
143
Commissioning
7
7.1 Requirements for commissioning
Requirements
Table 7- 1 Requirements
Prerequisite action See ...
Your system with SIMOTION C is installed. ChapterInstalling (Page 84)
Your system with SIMOTION C is wired. ChapterWiring (Page 91)
For networking via PROFIBUS DP
The PROFIBUS addresses of the bus nodes with which the
SIMOTION C communicates, are set.
The terminating resistors are switched on (at segment ends).
When networking via the Ethernet, the IP address / subnet mask of the
bus nodes with which the SIMOTION C communicates, are set.
When networking via PROFINET IO, the PROFINET device names of the
bus nodes with which the C240 PN communicates, are set
ChapterNetworking (Page 122)
Cha
pterConfiguring an Ethernet subn
et on the
Ethernet interface (Page 127)
Cha
pterConfiguring an Ethernet subn
et on the
PROFINET interface (C240 PN) (Page 129)
System requirements
Note
The readme file for the software version you are using provides information about the
hardware and software requirements.
Please take note of the information on the current CD for "SIMOTION SCOUT"!
For online operation, a connection must be established between the PG/PC and the
SIMOTION C via PROFIBUS DP, Ethernet or PROFINET (C240 PN), see chapter Overview
of wiring di
agram (Page 94).
The program
ming device must be equipped with a PROFIBUS or Ethernet card.
You need an MMC adapter to write to the micro memory card (SIMOTION Kernel update) on
the PG/PC, see chapter Writing, formatting and erasing the Micro M
emory Card (Page 147).
