Commissioning
7.3 Initial Power ON
SIMOTION C
146 Operating Instructions, 02/2012
7.3 Initial Power ON
Requirements
● You have completed installation and the wiring of your system with SIMOTION C.
● The micro memory card is inserted.
● The mode selector must be set to STOP!
Initial Power ON
Switch on the power supply module.
● The 24 VDC LED on the power supply module is illuminated.
● On the SIMOTION C:
– The 5 VDC LED illuminates.
– All other LEDs light up briefly (approx. 2 seconds).
Note
For C230-2
With an empty micro memory card, the SIMOTION Kernel on the C230-2 is copied to
the micro memory card during power-up. This increases the duration of the power-up
by about 1.5 minutes.
For C240 / C240 PN
If a micro memory card is not inserted in the C240 or if the micro memory card does
not contain a SIMOTION Kernel, all LEDs except the RUN LED are illuminated on the
SIMOTION C240.
