3.7 Possible uses of onboard drive and
measuring system interface in the application (C230-2, C240)
SIMOTION C
Operating Instructions, 02/2012
67
Note
Use of the drive and encoder inte
rfaces
as standard outputs and
counter inp
uts is only
possible via their direct I/O addr
ess. Symbolic assignment is n
ot available for this
application.
