Operating and fault messages
© Siemens AG 2003 All Rights Reserved
9-68 SIMOTION Safety Unit (AP) - Edition 06.2003
Display Error description Corrective
measure
F042 Error, input X3.3 See 2)
F043 Error, input X3.4 See 2)
F044 Error, input X3.5 See 2)
F045 Error, input X3.6 See 2)
F046 Error, input X3.7 See 2)
F047 Error, input X3.8 See 2)
F048 Error, input X3.9 See 2)
F049 Error, input X3.10 See 2)
F050 Error, input X3.11 See 2)
F051 Error, input X3.12 See 2)
F052 Error, input X3.13 See 2)
F053 Error, input X3.14 See 2)
F054 Error, input X3.15 See 2)
F055 Error, input X3.16 See 2)
F056 – F059
Not assigned
-
F060 Error, output X6.1 See 3)
F061 Error, output X6.3 See 3)
F062 Error, output X6.5 See 3)
F063 Error, output X6.7 See 3)
F064 Error, output X2.1 See 3)
F065 Error, output X2.2 See 3)
F066 Error, output X2.3 See 3)
F067 Error, output X2.4 See 3)
F068 – F069
Not assigned
-
F070 Error, output X6.2 See 3)
F071 Error, output X6.4 See 3)
F072 Error, output X6.6 See 3)
F073 Error, output X6.8 See 3)
F074 Error, output X2.5 See 3)
F075 Error, output X2.6 See 3)
F076 Error, output X2.7 See 3)
F077 Error, output X2.8 See 3)
Corrective measures for system errors:
1) Restart the device (INIT). Replace the device if the error reoccurs.
2) Check the wiring and correct if necessary. Specifically check the
parameterization of the sensor supply (external/internal). A more precise
statement on the source of the error can only be made after evaluation of the
error entries in the diagnosis buffer.
3) Check the wiring and correct if necessary. A more precise statement on the
source of the error can only be made after evaluation of the error entries in the
diagnosis buffer.
