Operating and fault messages
© Siemens AG 2003 All Rights Reserved
SIMOTION Safety Unit (AP) - Edition 06.2003
9-69
Table 9-2 Error messages requiring acknowledgement
Display Error description
F101 Over run cam static "1"
F102 Over run cam failed
F103 Over run cam static "0"
F104 Overtravel distance to long
F105 Ramp up cam failed
F106 Operating mode change not in TDC
F107 Short circuit at mode selector switch
F108 Speed monitor
F109 Runtime error, channel 1 (valve 1)
F110 Runtime error, channel 2 (valve 2)
F111 Runtime error, channel 3 (valve 3)
F112 Runtime error, channel 4 (EMERGENCY OFF output signal)
F113 Light curtain mode selection (1 cycle/2 cycle)
F114 Short circuit or "0" at light curtain mode selector switch
F115 Setting - dynamic cam
F122 Discrepancy error, transfer point
F123 Error in dynamic valve control, channel 1
F124 Error in dynamic valve control, channel 2
F125 Error in dynamic valve control, channel 3
F316 Restart inhibit, EMERGENCY OFF is set
F317 Restart inhibit, safety guard is set
F318 Restart inhibit, light curtain is set
F319 Restart inhibit, EMERGENCY OFF output signal
F320
*)
Safety gate closed – not ready for acknowledge (blocked)
F321
*)
Safety gate closed – ready for acknowledge
This error can only be acknowledged in the Setup operating mode
*)
If the safety gate display is parameterized for the fault lamp.
