Pin Name Type Pin Name Type Pin Name Type
16 CTREN3.1 C 33 Not assigned 49 CTREN3.2 C
17 CTREN4.1 C 50 CTREN4.2 C
Signal names
Table 4-7 Signal names for drives with analog interface
Signal name Meaning
SETP[1 to 4] Setpoint
REFPOT[1 to 4] Reference potential for setpoint (analog ground)
CTREN[1.1 to 4.1], CTREN[1.2 to 4.2] Controller-enable contact
Table 4-8 Signal names for stepper drives:
Signal name Meaning
PULS[1 to 4], PULS[1 to 4]_N Clock pulse is inverted and not inverted
DIR[1 to 4], DIR[1 to 4]_N Clock pulse inverted and non-inverted
ENABLE[1 to 4], ENABLE[1 to 4]_N Controller enable inverted and non-inverted
GND Signal ground
Signal type
O - signal output
VO - voltage output
K - switching contact
Drives with analog interface
Signals:
One voltage signal and one enable signal are provided per axis.
● Setpoint (SETP)
Analog voltage signal in the ±10 V range for the output of a speed setpoint.
● Reference potential (REFPOT)
Reference potential (analog ground) for the setpoint signal, connected internally to logic
ground.
● Controller enable (CTREN)
Contact assembly mated set (NO contact), used for axis-specific enabling of the drive, e.g.
a SIMODRIVE drive unit. The RF signal to the drive is set as soon as the controller enable
is signaled by the user program.
Interfaces
4.5 Onboard drive interface (C230-2, C240)
SIMOTION C
50 Operating Instructions, 11/2016, A5E33441428B
