Wizards
4.1 Example wizard
Intelligent Operator Panel (IOP)
34 Operating Instructions, 08/2015, FW V1.6.1, A5E00110011B AF
5.
Select "Yes (Enter Motor Data)
" to manually enter the
motor data from the rating label of the motor.
OR
6.
Select "No (Enter Motor Code)
" to enter the motor code
from the motor rating label.
All the relevant motor data will be automatically entered.
7.
The IOP will then present a number of screens, spec
ific to your selection of Step 5 or
Step 6. Enter the relevant data in the appropriate fields as they are presented. You will
automatically advanced through the commissioning process. Once the motor data has
been entered, the steps shown below will be presented.
8.
Select the Technology Application characteristics of the
application.
11.
Select the required macro source.
See
Basic commissioning with IOP (Page 33).
