6.3 Parameters
Intelligent Operator Panel (IOP)
Operating Instructions, 08/2015, FW V1.6.1, A5E00110011B AF
67
My parameters
This option allows the user to select the parameters that
they wish to list. The user is presented with a list of param
e-
ters that can be selected. Once selected
- only those pa-
rameters are displayed when the "My Parameters" option is
selected. There are ad
ditional options that allow the user to
manage their list of parameters.
Copying the "My Parameters" list to another IOP
When a "My Paramters" lists is created, it saves the lists in
the config.bin
file on the IOP.
To copy the config.bin, the following procedure should be
pe
rformed:
1.
Connect the IOP via the USB to your PC (the IOP will
enter "Mass Storage" mode.
2.
Navigate to the
config
folder (shown in the screenshot
and highlighted in red).
3.
Copy the
config.bin
file to a suitable location on your PC.
4.
Disconnect the IOP and connect a new IOP and copy the
config.bin
file to the new IOP.
Configuration file location
Changed parameters
When the "Changed parameters" option is selected the IOP
will search the Inverter parameter list for all th
e parameters
that have had their values changed from the factory default
settings.
Once the search is complete, the screen will present a list of
all parameters that have changed values.
The individual parameters can be accessed so that their cu
r-
rent values can be displayed and modified if necessary.
