Controlling the safety functions
5.4 Activating "SBC" via the Safe Brake Adapter
Safety Integrated
Function Manual, 07/2016, A5E03264275A
89
Table 5- 23 Terminal block X14, interface to the load
Connection
Signal
Description
X14.1
BR L
Supply voltage: 230 VAC
Current consumption: 2 A, only for brakes with brake rectifier
X14.2 BR N
Max. connectable cross-section 2.5 mm
2
WARNING
Danger to life if the permissible cable length of the brake control is exceeded
If the permissible cable length of the brake control is exceeded this can result in death or
serious injury in the event of an error.
• The maximum permissible cable length of 300 m between the 230 VAC Safe Brake
Adapter and the brake must be carefully maintained.
• To accurately calculate the maximum cable length, see the SINAMICS Low Voltage
Configuration Manual on the customer DVD supplied with the device.
Table 5- 24 Terminal block X15, fast de-energization
Connection
Signal
Description
X15.1
AUX1
Supply voltage: 230 VAC
Current consumption: 2 A
X15.2
AUX2
Max. connectable cross-section 2.5 mm
2
Spare fuse
The type of spare fuse is as follows: 2 A, time-lag.
Note
Correctly mounting the housing cover after replacing a fuse
An adhesive label is provided on the housing cover indicating the position of the connector.
Mou
nt the cover in the correct position so that the inscription of the label matches the actual
connectors.
