Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
130 Operating Instructions, 07/2012, A5E03728167
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
r0085 CO: Actual re-active
current [A]
- - - P2002 - Float 3
Displays re-active (imaginary part) of motor current.
Dependency: Applies when V/f control is selected in P1300 (control mode); otherwise, the display shows the value zero.
r0086 CO: Actual active current
[A]
- - - P2002 - Float 3
Displays active (real part) of motor current.
Dependency: See r0085
r0087 CO: Actual power factor - - - - - Float 3
Displays the actual power factor.
P0095[0...9] CI: Display PZD signals - 0 T 4000H - U32 /
I16
3
Selects source of display for PZD signals.
Index: [0] 1st PZD signal
[1] 2nd PZD signal
... ...
[9] 10th PZD signal
r0096[0...9] PZD signals [%] - - - - - Float 3
Displays PZD signals.
Index: [0] 1st PZD signal
[1] 2nd PZD signal
... ...
[9] 10th PZD signal
Note: r0096 = 100 % corresponds to 4000 hex.
P0100 Europe / North America 0 - 2 0 C(1) - - U16 1
Determines whether power settings are expressed in [kW] or [hp] (e.g. Rated motor power P0307).
The default settings for the rated motor frequency P0310 and maximum frequency P1082 are set
automatically here, in addition to reference frequency P2000.
0 Europe [kW], motor base frequency is 50 Hz
1 North America [hp], motor base frequency is 60 Hz
2 North America [kW], motor base frequency is 60 Hz
Dependency: Where:
• Stop inverter first (i.e. disable all pulses) before you change this parameter.
• P0100 can only be changed with P0010 = 1 (Commissioning mode) via the respective interface.
• Changing P0100 resets all rated motor parameters as well as other parameters that depend on the
rated motor parameters (see P0340 - calculation of motor parameters).
P0199 Equipment system
number
0 - 255 0 U, T - - U16 4
Equipment system number. This parameter has no operation effect (only for factory purposes).
r0206 Rated inverter power
[kW] / [hp]
- - - - - Float 2
Displays nominal rated motor power from inverter.
Dependency: Value is displayed in [kW] or [hp] depending on setting for P0100 (operation for Europe / North America).
r0207[0...2] Rated inverter current [A] - - - - - Float 2
Displays rated inverter current.
Index: [0] Rated inverter current
