Siemens SINUMERIK 802D sl Operator's Manual

System overview
2.2 Operator panel
SINUMERIK 802D sl pro - Milling
10 Control system overview for machine tools' sales people, 07/2008
2.2 Operator panel
The operator panel front consists of an operator panel with a 10.4 inch color TFT display, 8 +
2 horizontal and 8 vertical softkeys, and a CNC keyboard (horizontal or vertical options
available). This facilitates clear and user-friendly operation of the machine functions. We also
offer the coordinated machine control panel MCP 802D sl with feed and spindle override.
Highlights
● All relevant functions at a glance, thanks to horizontal and vertical softkeys
● Brilliant color display, balanced and high-quality design of operator components
● Easy data handling thanks to the easily accessible Compact Flash card slot on the front
2.3 Handheld unit
For the purpose of setting up the machine, you can install the mini handheld unit pictured
below.
Highlight
● Operation as close as possible to the workpiece via a mobile handheld unit

Siemens SINUMERIK 802D sl Specifications

General

Brand	Siemens
Model	SINUMERIK 802D sl
Category	Controller
Language	English
